Brand | Xtuga Audio |
Item model | Xtuga IEM1200 |
BodyPack Quantity | 4 IEM1200 BodyPack |
Product Dimensions | 21.65 x 14.17 x 3.54 inches |
Item Weight | 3.35 Kg |
Batteries | 2 AA batteries required. |
Audio Jack | 3.5 mm Jack |
Color | Black |
Special features | Volume Control, Lightweight |
ASIN | B07NSX1QPX |
Product Description:
IEM1200 wireless In Ear Monitor System 2 Channel Monitoring 4 bodypacks
Specification: Transmitter
Case specification:standard 1U
Case material:metal panel
Oscillation mode:PLL synthesized
Frequency stability:±0.005%
Frequency range:550-580MHz
Frequency interval:32MHz
Preset Channel: 40 channels separately set 4 groups
Operate mode:manual adjust
Max Deviation:±48KHz
Frequency response:50Hz~15KHz±3dB
Transmit output power:100mW(50Ω)
Harmonic radiation:<4NW
AF input:XLR,φ6.35mm jack
Earphone load impedance:≥16Ω
Current consumption:DC 12V/250mA
Antenna socket:TNC socket(50Ω)
Receiver:
Oscillation mode:PLL Synthesized
Frenquency range:550-580MHz
Preset channel:40 channels separately set 4 groups
Operate mode:manual adjust
Receiving mode:single tuning
Sensitivity:deviation 25 khz,with conecting 7dBuV,S/N>78dB
Max Deviation:±48KHz
Comprehensive T.H.D:>94db(1KHZ-A)
Comprehensive Reaponse::50Hz~15KHz±3dB
Output power:(32Ω)2x35mw@1KHz
Earphone load impedance:≥16Ω
Out socket:φ3.5mm stereo earphone socket
Volume output adjusts:adjust when using
Power box :batteries AAX2
Current drain:3V/120mA(Under the mediant degrees of the volume control)
Package Include(Whole system):
Transmitter × 1
Bodypack receiver(with earphone) × 4
Antenna × 2
Cable Line × 4/8
Power Adapter × 1
User Manual × 1
Xtuga IEM1200 4 Bodypacks Inexpensive Best Personal In Ear Monitor System
- Código de Producto: Xtuga-IEM1200-4
Brand | Xtuga Audio |
Item model | Xtuga IEM1200 |
BodyPack Quantity | 4 IEM1200 BodyPack |
Product Dimensions | 21.65 x 14.17 x 3.54 inches |
Item Weight | 3.35 Kg |
Batteries | 2 AA batteries required. |
Audio Jack | 3.5 mm Jack |
Color | Black |
Special features | Volume Control, Lightweight |
ASIN | B07NSX1QPX |
Product Description:
IEM1200 wireless In Ear Monitor System 2 Channel Monitoring 4 bodypacks
Specification: Transmitter
Case specification:standard 1U
Case material:metal panel
Oscillation mode:PLL synthesized
Frequency stability:±0.005%
Frequency range:550-580MHz
Frequency interval:32MHz
Preset Channel: 40 channels separately set 4 groups
Operate mode:manual adjust
Max Deviation:±48KHz
Frequency response:50Hz~15KHz±3dB
Transmit output power:100mW(50Ω)
Harmonic radiation:<4NW
AF input:XLR,φ6.35mm jack
Earphone load impedance:≥16Ω
Current consumption:DC 12V/250mA
Antenna socket:TNC socket(50Ω)
Receiver:
Oscillation mode:PLL Synthesized
Frenquency range:550-580MHz
Preset channel:40 channels separately set 4 groups
Operate mode:manual adjust
Receiving mode:single tuning
Sensitivity:deviation 25 khz,with conecting 7dBuV,S/N>78dB
Max Deviation:±48KHz
Comprehensive T.H.D:>94db(1KHZ-A)
Comprehensive Reaponse::50Hz~15KHz±3dB
Output power:(32Ω)2x35mw@1KHz
Earphone load impedance:≥16Ω
Out socket:φ3.5mm stereo earphone socket
Volume output adjusts:adjust when using
Power box :batteries AAX2
Current drain:3V/120mA(Under the mediant degrees of the volume control)
Package Include(Whole system):
Transmitter × 1
Bodypack receiver(with earphone) × 4
Antenna × 2
Cable Line × 4/8
Power Adapter × 1
User Manual × 1
